Basic Info.

Model NO. 727CJ 727C 728CJ 728C 728CY 729CJ 729C Transport Package as Per Client′s Requirement Trademark Yiding Origin China HS Code 8482102000 Production Capacity 60000 Pieces/Month

Product Description

Angular contact ball bearing 727CJ 727C
Quick Details
Structure: Angular Contact
Type: Ball
Bore Size: 3 - 1000 mm
Outside Diameter: 5 - 2500 mm
Model Number: 727CJ 727C 728CJ 728C 728CY 729CJ 729C
Precision Rating: P0, P5, P6
Seals Type: Z ZZ RS 2RS RW 2RW N
Number of Row: Single Row
Material: Chrome, stainless steel, Gcr15
Clearance: C2, C3, C4, C5
Vibration: V1, V2, V3, V4
SAMPLES available: OEM service
QUALITY bearings: Low price
Cage: Brass cage, nylon cage, steel cage

Specifications
1. In high speed application
2. Combination arbitrarily
3. Lower noise and higher speed
4. Higher rated load

Packaging & Delivery
Packaging Detail: Angular contact ball bearing 1. Neutral Package: Plastic Bag + Carton + Pallet; 2. Commercial Package: Plastic Bag + Box + Carton + Pallet; 3. As the clients' requirement.
Delivery Detail: 5-30days

Applications
The raceways of angular contact ball bearing in the inner and outer rings can have relative displacement on the horizontal axis. Therefore, this design can make it withstand combined loads, namely, supporting radial and axial loads simultaneously. The axial load capacity of angular contact ball bearing improves with the increasing contact angle.


723CJ	36023	3×10×4	0.0017
723C	36023J	3×10×4	0.0017
723CY	36023Y	3×10×4	0.0017
724CJ	36024	4×13×5	0.003
724C	36024J	4×13×5	0.003
724CY	36024F	4×13×5	0.003
725CJ	36025	5×16×5	0.005
725C	36025J	5×16×5	0.005
725CY	36025F	5×16×5	0.005
726CJ	36026	6×19×6	0.008
726C	36026J	6×19×6	0.008
726CY	36026F	6×19×6	0.008
726/HNYA	36026KN	6×19×6	0.008
727CJ	36027	7×22×7	0.013
727C	36027J	7×22×7	0.013
728CJ	36028	8×24×8	0.018
728C	36028J	8×24×8	0.018
728CY	36028F	8×24×8	0.018
729CJ	36029	9×26×8	-
729C	36029J	9×26×8	-
7200C	36200J	10×30×9	0.0294
7200C	36200	10×30×9	0.0294
