Product NameTaper Roller BearingBrandCHIK or OEMTypeTaper rollerModel Number30 series,31series,32seriesBearing MaterialGCr15Retainer MaterialSteelNumber of RowSingle RowSeals TypeOpen,PrecisionP5 P6CertificateISO9001:2008Scope of applicationCar,mill,mining,metallurgy,plastics machinery and other industries


Tapered roller bearing is mainly used to bear the joint mainly consisting of radial load and axial load compared with angular Contact ball bearing Carrying capacity is big, limit rotational speed is low Tapered roller bearings can withstand axial load in onedirection, can limit axial displacement of shaft or housing in one direction

According to row can be have sing row double row and four row bearings
Material:Ring Material Chrome Steel,Carbon steel,Stainless steel
Cage :Nylon,steel,brass
Greese :As your requirement,such as SRL,PS2,Alvania R12 and so on.
Vibration Level:Z1V1,Z2V2,Z3V3
Clearance:C2,C0,C3,C4,C5
Tolerance Codes:ABEC-1,ABEC-3,ABEC-5,
Payment Terms:T/T,L/C,Paypal,Western Union

ISOGOSTDimensions (mm)Basic Load Rating (N)Limitting speed ( r/min )WeightLubricationdDBTCDyn. CStat. C0GreaseOil313052730525621718133800040000560075000.26313062730630721920144730050000500067000.39313072730735802122156160067000450060000.52313082730840902325177370081500400053000.7231309273094510025271891300102000340045000.95313102731050110272919106000120000320043001.2313112731155120293121121000137000280038001.55313122731260130313322145000166000260036001.9313132731365140333623165000193000220032002.35313142731470150353825187000220000200030002.95313152731575160374026209000245000190028003.5313162731680170394227224000265000190028004.05313172731785180414428242000285000180026004.6313182731890190434630264000315000170024005.9313192731995200454932292000355000170024006.953132027320100215515635374000465000160022008.6

VI. OUR ADVANTAGES
- 16 years export experience
- Strict quality control
- Delivery in time
- OEM service is available with good prices
- Your success is our business and future
