Sk/NSK Spherical Roller Bearing 23228MB/W33 Used for Deceleration Device
Shandong TFN Bearing Industry Co., Ltd.Base Info
Description
Quality Control Process 1.Assembly 2.Windage test2.Windage test 3.Cleaning 4.Rotary test 5.Greasing and gland 6.Noise inspection 7.Appearance inspection 8.Rust prevention 9.Product packaging Application low noise machine,automobile,motorcycle,and the general machinery and etc.
Limiting speeds(rpm)Mass(Kg) d D B rs min Cr Cor Grease Oil (Approx.) 232 Series 23218 90 160 52.4 2 315 455 1,800 2,800 4.45 23218K 90 160 52.4 2 315 455 1,800 2,800 4.32 23218KW33C3 90 160 52.4 2 315 455 1,800 2,800 4.32 23218W33C3 90 160 52.4 2 315 455 1,800 2,800 4.45 23220 100 180 60.3 2.1 405 580 1,600 2,500 6.47 23220K 100 180 60.3 2.1 405 580 1,600 2,500 6.28 23220KW33C3 100 180 60.3 2.1 405 580 1,600 2,500 6.28 23220W33C3 100 180 60.3 2.1 405 580 1,600 2,500 6.47 23222 110 200 69.8 2.1 515 760 1,400 2,200 9.71 23222K 110 200 69.8 2.1 515 760 1,400 2,200 9.43 23222KW33C3 110 200 69.8 2.1 515 760 1,400 2,200 9.43 23222W33C3 110 200 69.8 2.1 515 760 1,400 2,200 9.71 23224 120 215 76 2.1 585 880 1,300 2,000 12.1 23224K 120 215 76 2.1 585 880 1,300 2,000 11.7 23224KW33C3 120 215 76 2.1 585 880 1,300 2,000 11.7 23224W33C3 120 215 76 2.1 585 880 1,300 2,000 12.1 23226 130 230 80 3 685 1,060 1,200 1,900 14.3 23226K 130 230 80 3 685 1,060 1,200 1,900 13.9 23226KW33C3 130 230 80 3 685 1,060 1,200 1,900 13.9 23226W33C3 130 230 80 3 685 1,060 1,200 1,900 14.3 23228 140 250 88 3 805 1,270 1,100 1,700 18.8 23228K 140 250 88 3 805 1,270 1,100 1,700 18.2 23228KW33C3 140 250 88 3 805 1,270 1,100 1,700 18.2 23228W33C3 140 250 88 3 805 1,270 1,100 1,700 18.8 23230 150 270 96 3 935 1,460 1,000 1,600 24.1 23230K 150 270 96 3 935 1,460 1,000 1,600 23.4 23230KW33C3 150 270 96 3 935 1,460 1,000 1,600 23.4 23230W33C3 150 270 96 3 935 1,460 1,000 1,600 24.1 23232 160 290 104 3 1050 1,660 960 1,500 30 23232K 160 290 104 3 1050 1,660 960 1,500 29.1 23232KW33C3 160 290 104 3 1050 1,660 960 1,500 29.1 23232W33C3 160 290 104 3 1050 1,660 960 1,500 30 23234 170 310 110 4 1180 1,960 910 1,400 36.8 23234K 170 310 110 4 1180 1,960 910 1,400 35.7 23234KW33C3 170 310 110 4 1180 1,960 910 1,400 35.7 23234W33C3 170 310 110 4 1180 1,960 910 1,400 36.8 23236 180 320 112 4 1230 2,000 850 1,300 39 23236K 180 320 112 4 1230 2,000 850 1,300 37.8 23236KW33C3 180 320 112 4 1230 2,000 850 1,300 37.8 23236W33C3 180 320 112 4 1230 2,000 850 1,300 39 23238 190 340 120 4 1400 2,330 790 1,200 47.6 23238K 190 340 120 4 1400 2,330 790 1,200 46.2 23238KW33C3 190 340 120 4 1400 2,330 790 1,200 46.2 23238W33C3 190 340 120 4 1400 2,330 790 1,200 47.6 23240 200 360 128 4 1610 2,640 750 1,200 57.2 23240K 200 360 128 4 1610 2,640 750 1,200 55.5 23240KW33C3 200 360 128 4 1610 2,640 750 1,200 55.5 23240W33C3 200 360 128 4 1610 2,640 750 1,200 57.2 23244 220 400 144 4 2010 3,350 670 1,000 80 23244K 220 400 144 4 2010 3,350 670 1,000 77.6 23244KW33C3 220 400 144 4 2010 3,350 670 1,000 77.6 23244W33C3 220 400 144 4 2010 3,350 670 1,000 80 23248 240 440 160 4 2430 4,100 610 940 108 23248K 240 440 160 4 2430 4,100 610 940 105 23248KW33C3 240 440 160 4 2430 4,100 610 940 105 23248W33C3 240 440 160 4 2430 4,100 610 940 108 23252 260 480 174 5 2760 4,700 560 860 141 23252K 260 480 174 5 2760 4,700 560 860 137 23252KW33C3 260 480 174 5 2760 4,700 560 860 137 23252W33C3 260 480 174 5 2760 4,700 560 860 141 23256 280 500 176 5 2930 5,150 510 790 150 23256K 280 500 176 5 2930 5,150 510 790 145 23256KW33C3 280 500 176 5 2930 5,150 510 790 145 23256W33C3 280 500 176 5 2930 5,150 510 790 150 23260 300 540 192 5 3450 6,000 470 730 193 23260K 300 540 192 5 3450 6,000 470 730 187 23260KW33C3 300 540 192 5 3450 6,000 470 730 187 23260W33C3 300 540 192 5 3450 6,000 470 730 193 23264 320 580 208 5 4180 6,370 500 630 260 23264/W33 320 580 208 5 4180 6,370 500 630 259 23264K 320 580 208 5 3900 6,800 500 630 253 23264K/W33 320 580 208 5 3900 6,800 500 630 252 23280 400 720 256 6 5800 10,400 340 430 530 23280/W33 400 720 256 6 5800 10,400 340 430 530 23280K 400 720 256 6 6150 11,300 340 430 516 23280K/W33 400 720 256 6 6150 11,300 340 430 515 23284CAK 420 760 272 7.5 7250 11,900 400 550 654 23284CAK/W333 420 760 272 7.5 7250 11,900 400 550 654 23296 480 870 310 7.5 7850 14,400 260 340 837
spherical roller bearing packaging
FAQ of spherical roller bearing




FAQ of spherical roller bearing
1.Q:Are you a factory or trading company?
A:SEMRI Bearing is specialized in manufacturing and exporting bearings.
SEMRI Bearing have own factory and warehouse.
2.Q:Can I get some samples and do you offer the sample free?
A:Yes, sure, SEMRI Bearing are honored to offer you samples.Can you buy a ticket ?3.Q:What is the payment?
A: 30% T/T In Advance, 70% T/T Against Copy Of B/L
B: 100% L/C At Sight
4.Q:What is the MOQ for bearing?
A: SEMRI Bearing MOQ is 1 pc.
5.Q:What kind of service you can offer?
A:Technology support;Installation guidance;OE
