* P69f3 China Standard and ISO and ANSI Industrial Machinery Conveyor Chain
Qingdao Star Machine Technology Co., Ltd.- Standard or Nonstandard:Standard
- Application:Textile Machinery, Garment Machinery, Conveyer Equipment, Packaging Machinery, Electric Cars, Motorcycle, Food Machinery, Marine, Mining Equipment, Agricultural Machinery, Car
- Surface Treatment:Polishing
- Structure:Combined Chain
- Material:Alloy
- Type:Customized Conveyor Chain
Base Info
- Model NO.:P69f3
- Transport Package:According to Client Requests
- Specification:Customized
- Trademark:SMCC
- Origin:China
- HS Code:7315119000
- Production Capacity:700000meters Per Year
Description
Weight per meter q kg/mLmax mm Lcmax mm *P69F3 69.85 15.88 17 8.28 35.2 38.5 20.6 4.00/3.26 60.8/13669 66.9 1.5 P69.85F1 69.85 31.75 25.4 14.27 66.4 73.5 34.93 7.9 170.0/38243 187 8.76 P75F8-G-2 75 31.8 16.1 8 40 40 22 3.2 60.8/13668 66.9 2.43 P75F35 75 16 16.1 8 33.3 36 22 3.2 60.00/13488 66 1.75 P75F53 75 15.5 18 7.92 35.4 39.1 22 3.25 29.40/6609 32.3 1.73 P75F58-S-75 75 15.5 18 7.92 35.4 39.1 22 3.25 29.4/6609 32.3 1.73 P76.2F2 76.2 50 26 24 69.6 74.7 59.5 8 350.0/79544 385 19 P76.2F10 76.2 11.91 11 5.94 28 30.4 18.5 3.25 31.8/7148 35 1.3 P76.2F14 76.2 38.1 25.4 11.1 50.9 55 28.6 4.8 85.0/19108 94 5.8 P76.2F25 76.2 43.18 49.28 23.9 130 130 60.45 14.2 697.0/156691 766.7 32.3 P76.2F35 76.2 12.07 13 8.1 24.5 26.5 18 1.85 29.0/6519 31.9 0.77 P76.2F38 76.2 40 25.4 14.7 57.5 62 36 6 116.0/26077 127 8 P76.2F71 76.2 28.7 31.75 14.2 66.2 72 38.1 6.4 180.00/41200 198 7.8 P78.11F11 78.11 31.75 31.75 15.88 86.5 86.5 38.1 9.53 161.6/36329 177.8 11.34 P80F1 80 42 24 15 55 60 60 6 250.0/56202 275 11.9 P80F5 80 28 34 16 68 72 45 5.00/8.00 190.0/43181 209 8.8 P80F6 80 30 32 15 58.6 62.6 60 5 98.0/22272 108 9.75 P80F10 80 42 22 15 53 58 60 6 250.0/56202 275 11.4 P80F37 80 26 25 14 59.3 59.3 35 6.00/5.00 155.0/34845 170.5 5.72 P80F35 80 42 23 16 56 61.5 60 6 160.0/35969 176 11.5 P95F3 95 30 32 14 - 67.5 41 6 112.0/25178 123.2 7.2 P100H 100 20 28 14 - 62 40 5 103.0/23170 113.3 4.99 P100F7 100 29 30 14.5 - 71 38.1 6 95.0/21356 104.5 6.72 P100F25 100 25.4 31.5 14 62.6 77.5 38.1 6 95.0/21356 104.5 6.17 P100F52 100 38 18 9.53 47 49.3 32 5 86.7/19504 95.3 4.67 P100F53 100 52 21 14 46 51 40 5.00/4.00 110.0/24728 121 7.45 P100F56 100 35 13.5 10 - 46 30 5 70.0/15736 77 3.98 P100F77 100 38 17.5 11.3 48 48 32 4.5 65.0/14612 71.5 4.42 P100F84 100 38 22 9.5 57.5 57.5 35 6 70.0/15736 77 6.27 P100F92 100 60 38 20 81 94 47 8 220.0/49457 242 16.9 P100F111 100 29 30 14.5 71 71 38.1 6 95.0/21356 104.5 6.75 P100F114 100 40 23 12 - 56 32 6 100.0/22480 115 5.96 P100F122 100 38 17.5 11.3 41.8 45.9 32 4.5 65.0/14612 71.5 4.33 P100F125 100 22.2 22 11.3 54.5 58 32 6 110.0/24728 121 4.45 P100F161-S 100 30 31.6 15.9 - 80 38.1 8 130.0/29225 143 8.5 P100F166 100 25 30 14.5 - 71 38.1 6 95.0/21356 105 6.36 P100F196 100 38 18 10 - 51.5 29 5.6 100.0/22480 110 4.8 P100F223 100 29 30 14.5 - 71 38.1 6 225.0/50580 247.5 9.46 P100F248 100 50 24 15 - 52 35 4 100.0/22480 110 6.4 P100F250 100 15.88 19 7.92 37.4 40 26 3.2 30.0/6744 33 1.86 P100F268 100 22.2 22 11.3 - 51 32 4.5 65.0/14612 71.5 3.6 P100F279 100 50 33 14 - 70 62 6 112.0/25177 123.2 14.33 P100F355 100 15.88 16 8.3 35 48 22 3.25 32.0/7194 35.2 3 P100F360 100 20 25 14 60.6 65.8 35 6 120.0/26976 132 5.58 *Bush chain: d1 in the table indicates the external diameter of the bush.CONVEYOR CHAIN DESIGNED AND MANUFACTURED FOR THE MOST DEMANDING OF ENVIRONMENTS


CONVEYOR CHAIN DESIGNED AND MANUFACTURED FOR THE MOST DEMANDING OF ENVIRONMENTS
Qingdao Star Machine Technology Co.,ltd. provides the highest quality materials and manufacturing methods to suit the most arduous of conveyor chain applications - from the transport of biomass fuels, to the recycling industry, paper & pulp, cement, steel-work, the wood industry and food processing.
Our conveyor chains, sprocket wheels and attachments are case-hardened to achieve the optimum balance between strength, durability and resistance to wear.
Our manufacturing is focused on metric pitch conveyor chains that include:
International Standards DIN 8167/ISO 1977 M series
DIN 8165/ISO 1977 FV series
SMS 1968 S series
CONSTRUCTION OF THE CHAIN
Two different sizes of roller chain, showing construction.
There are two types of links alternating in the bush roller chain. The first type is inner links, having two inner plates held together by two sleeves or bushings upon which rotate two rollers. Inner links alternate with the second type, the outer links, consisting of two outer plates held together by pins passing through the bushings of the inner links. The "bushingless" roller chain is similar in operation though not in construction; instead of separate bushings or sleeves holding the inner plates together, the plate has a tube stamped into it protruding from the hole which serves the same purpose. This has the advantage of removing one step in assembly of the chain.
VARIANTS DESIGN
Layout of a roller chain: 1. Outer plate, 2. Inner plate, 3. Pin, 4. Bushing, 5. Roller
If the chain is not being used for a high wear application (for instance if it is just transmitting motion from a hand-operated lever to a control shaft on a machine, or a sliding door on an oven), then one of the simpler types of chain may still be used. Conversely, where extra strength but the smooth drive of a smaller pitch is required, the chain may be "siamesed"; instead of just two rows of plates on the outer sides of the chain, there may be three ("duplex"), four ("triplex"), or more rows of plates running parallel, with bushings and rollers between each adjacent pair, and the same number of rows of teeth running in parallel on the sprockets to match. Timing chains on automotive engines, for example, typically have multiple rows of plates called strands.
USE
An example of two 'ghost' sprockets tensioning a triplex roller chain system
Roller chains are used in low- to mid-speed drives at around 600 to 800 feet per minute; however, at higher speeds, around 2,000 to 3,000 feet per minute, V-belts are normally used due to wear and noise issues.
A bicycle chain is a form of roller chain. Bicycle chains may have a master link, or may require a chain tool for removal and installation. A similar but larger and thus stronger chain is used on most motorcycles although it is sometimes replaced by either a toothed belt or a shaft drive, which offer lower noise level and fewer maintenance requirements.
The great majority of automobile engines use roller chains to drive the camshaft(s). Very high performance engines often use gear drive, and starting in the early 1960s toothed belts were used by some manufacturers.
Chains are also used in forklifts using hydraulic rams as a pulley to raise and lower the carriage; however, these chains are not considered roller chains, but are classified as lift or leaf chains.
Chainsaw cutting chains superficially resemble roller chains but are more closely related to leaf chains. They are driven by projecting drive links which also serve to locate the chain onto the bar.
Sea Harrier FA.2 ZA195 front (cold) vector thrust nozzle - the nozzle is rotated by a chain drive from an air motor
A perhaps unusual use of a pair of motorcycle chains is in the Harrier Jump Jet, where a chain drive from an air motor is used to rotate the movable engine nozzles, allowing them to be pointed downwards for hovering flight, or to the rear for normal forward flight, a system known as Thrust
WEAR
The effect of wear on a roller chain is to increase the pitch (spacing of the links), causing the chain to grow longer. Note that this is due to wear at the pivoting pins and bushes, not from actual stretching of the metal (as does happen to some flexible steel components such as the hand-brake cable of a motor vehicle).
With modern chains it is unusual for a chain (other than that of a bicycle) to wear until it breaks, since a worn chain leads to the rapid onset of wear on the teeth of the sprockets, with ultimate failure being the loss of all the teeth on the sprocket. The sprockets (in particular the smaller of the two) suffer a grinding motion that puts a characteristic hook shape into the driven face of the teeth. (This effect is made worse by a chain improperly tensioned, but is unavoidable no matter what care is taken). The worn teeth (and chain) no longer provides smooth transmission of power and this may become evident from the noise, the vibration or (in car engines using a timing chain) the variation in ignition timing seen with a timing light. Both sprockets and chain should be replaced in these cases, since a new chain on worn sprockets will not last long. However, in less severe cases it may be possible to save the larger of the two sprockets, since it is always the smaller one that suffers the most wear. Only in very light-weight applications such as a bicycle, or in extreme cases of improper tension, will the chain normally jump off the sprockets.
In industry, it is usual to monitor the movement of the chain tensioner (whether manual or automatic) or the exact length of a drive chain (one rule of thumb is to replace a roller chain which has elongated 3% on an adjustable drive or 1.5% on a fixed-center drive). A simpler method, particularly suitable for the cycle or motorcycle user, is to attempt to pull the chain away from the larger of the two sprockets, whilst ensuring the chain is taut. Any significant movement (e.g. making it possible to see through a gap) probably indicates a chain worn up to and beyond the limit. Sprocket damage will result if the problem is ignored. Sprocket wear cancels this effect, and may mask chain wear.
CHAIN STRENGTH
The most common measure of roller chain's strength is tensile strength. Tensile strength represents how much load a chain can withstand under a one-time load before breaking. Just as important as tensile strength is a chain's fatigue strength. The critical factors in a chain's fatigue strength is the quality of steel used to manufacture the chain, the heat treatment of the chain components, the quality of the pitch hole fabrication of the linkplates, and the type of shot plus the intensity of shot peen coverage on the linkplates. Other factors can include the thickness of the linkplates and the design (contour) of the linkplates. The rule of thumb for roller chain operating on a continuous drive is for the chain load to not exceed a mere 1/6 or 1/9 of the chain's tensile strength, depending on the type of master links used (press-fit vs. slip-fit)[citation needed]. Roller chains operating on a continuous drive beyond these thresholds can and typically do fail prematurely via linkplate fatigue failure.
The standard minimum ultimate strength of the ANSI 29.1 steel chain is 12,500 x (pitch, in inches)2. X-ring and O-Ring chains greatly decrease wear by means of internal lubricants, increasing chain life. The internal lubrication is inserted by means of a vacuum when riveting the chain together.
CHAIN STANDARDS
Standards organizations (such as ANSI and ISO) maintain standards for design, dimensions, and interchangeability of transmission chains. For example, the following Table shows data from ANSI standard B29.1-2011 (Precision Power Transmission Roller Chains, Attachments, and Sprockets) developed by the American Society of Mechanical Engineers (ASME). See the references for additonal information.
ASME/ANSI B29.1-2011 Roller Chain Standard SizesSizePitchMaximum Roller DiameterMinimum Ultimate Tensile StrengthMeasuring Load25.
For mnemonic purposes, below is another presentation of key dimensions from the same standard, expressed in fractions of an inch (which was part of the thinking behind the choice of preferred numbers in the ANSI standard):
