Zys Auto Wheel Hub Tapered Roller Bearing 32204 20*47*19.25mm Wheel Bearing
Luoyang Bearing Research Institute Co., Ltd.Base Info
Description
Overview
Product Description
1. Enhance the interior design.
2. Special cage design.
3. Improve the accuracy and adjust the internal clearance.
4. Ring with locking slot design to prevent rotation.Product ParametersBEARING NO. d D T 30202 15 35 11.75 30203 17 40 13.25 30204 20 47 15.25 30205 25 52 16.25 30206 30 62 17.25 30207 35 72 18.25 30208 40 80 19.25 30209 45 85 20.75 30210 50 90 21.75 30211 55 100 22.75 30212 60 110 23.75 30213 65 120 24.75 30214 70 125 26.25 30215 75 130 27.25 30216 80 140 28.25 30217 85 150 30.5 30218 90 160 32.5 30219 95 170 34.5 30220 100 180 37 30221 105 190 39 30222 110 200 41 30224 120 215 43.5 30226 130 230 43.75 30228 140 250 45.75 30230 150 270 49 30232 160 290 52 30234 170 310 57 30236 180 320 57 30238 190 340 60 30240 200 360 64 30302 15 42 14.25 30303 17 47 15.25 30304 20 52 16.25 30305 25 62 18.25 30306 30 72 20.75 30307 35 80 22.75 30308 40 90 25.25 30309 45 100 27.25 30310 50 110 29.25 30311 55 120 31.5 30312 60 130 33.5 30313 65 140 36 30314 70 150 38 30315 75 160 40 30316 80 170 42.5 30317 85 180 44.5 30318 90 190 46.5 30319 95 200 49.5 30320 100 215 51.5 30321 105 225 53.5 30322 110 240 54.5 30324 120 260 59.5 30326 130 280 63.75 30328 140 300 67.75 30330 150 320 72 30352 260 540 114 Designation d D T B C Load Ratings Fatigue Load Speed Ratings Mass Limit Lubrication mm Dynamic [C] Static [C0] Pu(kN) Grease Oil Kg. 32205 25 52 19,25 18 15 45.7 48.4 5.12 10000 13000 0.19 32206 30 62 21,25 20 17 64.4 62.7 6.93 9000 11000 0.28 32207 35 72 24,25 23 19 84.2 85.8 9.35 8000 9500 0.43 32208 40 80 24,75 23 19 93.5 95.2 10.78 7000 8500 0.53 32213 65 120 32,75 31 27 166.1 212.3 25.08 4000 5600 1.5 32214 70 125 33,25 31 27 172.7 228.8 26.95 3800 5300 1.6 32215 75 130 33,25 31 27 177.1 233.2 26.95 3600 5000 1.7 32216 80 140 35,25 33 28 205.7 269.5 31.35 3400 4500 2.05 32217 85 150 38,5 36 30 233.2 313.5 36.85 3200 4300 2.6 32218 90 160 42,5 40 34 276.1 374 42 3000 4000 3.35 32219 95 170 45,5 43 37 309.1 429 47 2800 3800 4.05 32220 100 180 49 46 39 350.9 484 53 2600 3600 4.9 32221 105 190 53 50 43 393.8 561 61 2600 3400 6 32222 110 200 56 53 46 442.2 627 67 2400 3200 7.1 32224 120 215 61,5 58 50 514.8 764.5 79 2200 3000 9.15 32226 130 230 67,75 64 54 605 913 94 2000 2800 1.15 32228 140 250 71,75 68 58 708 1100 110 1900 2600 1.45 32230 150 270 77 73 60 811 1254 123 1700 2400 17.5 32232 160 290 84 80 67 968 1540 145 1600 2200 2.55 32234 170 310 91 86 71 1111 1793 165 1500 2000 28.5 32236 180 320 91 86 71 1111 1793 165 1400 1900 29.5 32240 200 360 104 98 82 1331 2200 198 1300 1700 42.5 32244 220 400 114 108 90 1771 2970 255 1100 1500 60 32248 240 440 127 120 100 1969 3685 303 1000 1400 83.5 32252 260 480 137 130 106 2420 4015 330 900 1200 105 32260 300 540 149 140 115 3025 5225 402 800 1100 140 Model Number d(mm) D(mm) W(mm) Brand 33215 3007215E 75 130 41 ZYS 33214 3007214E 70 125 41 ZYS 33213 3007213E 65 120 41 ZYS 33212 3007212E 60 110 38 ZYS 33211 3007211E 55 100 35 ZYS 33210 3007210E 50 90 32 ZYS 33209 3007209E 45 85 32 ZYS 33208 3007208E 40 80 32 ZYS 33207 3007207E 35 72 28 ZYS 33205 3007205E 25 52 22 ZYS 33022 3007122E 110 170 47 ZYS 33021 3007121E 105 160 43 ZYS 33020 3007120E 100 150 39 ZYS 33019 3007119E 95 145 39 ZYS 33015 3007115E 75 115 31 ZYS 33013 3007113E 65 100 27 ZYS 33012 3007112E 60 95 27 ZYS 32314 7614E 70 150 54 ZYS 32313 7613E 65 140 51 ZYS 32312 7612E 60 130 48.5 ZYS 32311 7611E 55 120 45.5 ZYS 32310 7610E 50 110 42.25 ZYS 32309 7609E 45 100 38.25 ZYS 32308 7608E 40 90 35.25 ZYS 32307 7607E 35 80 32.75 ZYS 32306 7606E 30 72 28.75 ZYS 32305 7605E 25 62 25.25 ZYS 32304 7604E 20 52 22.25 ZYS 32224 7524E 120 215 61.5 ZYS 32222 7522E 110 200 56 ZYS 32221 7521E 105 190 53 ZYS 32220 7520E 100 180 49 ZYS 32219 7519E 95 170 45.5 ZYS 32218 7518E 90 160 42.5 ZYS 32217 7517E 85 150 38.5 ZYS 32216 7516E 80 140 35.25 ZYS 32215 7515E 75 130 33.25 ZYS 32214 7514E 70 125 33.25 ZYS 32213 7513E 65 120 32.75 ZYS 32212 7512E 60 110 29.75 ZYS 32211 7511E 55 100 26.75 ZYS
Company Profile
Tapered roller bearings refer to the radial thrust rolling bearings whose rolling body is a tapered roller. There are two types of small Angle and large Angle. The taper Angle is mainly subjected to radial and axial combined loads, which are usually in double use and reverse installation. The inner and outer seat rings can be installed separately, and the radial and axial clearance can be adjusted during installation and use. The large cone Angle mainly bears the combined axial and radial load, which is not used to bear the pure axial load separately.
The characteristics of tapered roller bearings:1. Enhance the interior design.
2. Special cage design.
3. Improve the accuracy and adjust the internal clearance.
4. Ring with locking slot design to prevent rotation.Product Parameters
Technical parameters of taper roller bearings:
