DesignationdDWTnomnmaxWeightItem no.[mm][mm][mm][Nm][rpm][kg]FE 412 Z41212427,0000.003300393FE 416 Z816121619,2000.006300400FE 420 Z1220123512,5000.007306041FE 422 Z1422125310,1000.008300405FE 423 Z152312629,2000.009300411FE 425 Z172512728,1000.011300415FE 427 Z192712837,4000.013300422FE 428 Z202812937,5000.013300430FE 430 Z2230121076,3000.014300435FE 432 Z2432121175,9000.016300439FE 433 Z2533121286,0000.016300445FE 435 Z2735121435,1000.017300448FE 437 Z2937121544,8000.018300455FE 438 Z3038121664,9000.019300460FE 442 Z3442121984,4000.018300463FE 443 Z3543122074,3000.022300469FE 448 Z4048122484,2000.024300478FE 453 Z4553122933,4000.022300482FE 455 Z4755123133,3000.026300487FE 458 Z5058123443,1000.029300489FE 459 Z5159123533,0000.03300494FE 463 Z5563123932,9000.032300497FE 468 Z6068124442,7000.034300501FE 470 Z6270124652,6000.035300505FE 473 Z6573124952,5000.037300508FE 478 Z7078125482,6000.039300511FE488Z8088126572,1000.045300514FE 508 Z100108128891,7000.055300519FE 528 Z120128121,1271,3000.066300522FE 648 Z240248122,6738000.131300524

MARKS
A large quantity of freewheel-clutches with varying design features and dimensions are  available  , depending on requirements such as: Torque, indexing frequency, idling speed and environment
The supporting equipment around the clutch has to be built accurately and of high quality for the
clutch to operate properly .This is why we offer support units or complete assemblies of freewheel clutches.

Packaging
