ANSI Standard Transmission Gear and Rack
Hangzhou Donghua Power Transmission Imp. & Exp. Co., Ltd.- Hardness：Hardened Tooth Surface
- Gear Position：External Gear
- Manufacturing Method：Rolling Gear
- Toothed Portion Shape：Spur Gear
- Material：C45
- Type：Circular Gear
Base Info
- Model NO.：Mould from M0.5 to M6
- Transport Package：Export Package
- Specification：ISO ANIS DIN KANA JIS GB ASA
- Trademark：DONGHUA
- Origin：China
- HS Code：84839000
- Production Capacity：3000PCS,Month
Description
Prossure angle 20°Material C45Mod. Hp HexS L 500 1000 2000 Teeth No. Lr Weight(kg) Teeth NO. Lr Weight(kg) Teeth NO. Lr Weight(kg) 1 14 15x15 159 449.51 0.82 318 999.02 1.50 636 1998.05 3.10 1.5 15.5 17x17 106 449.51 1.00 212 999.02 2.00 424 1998.05 4.00 2 18 20x20 80 502.65 1.40 159 999.02 2.70 318 1998.05 5.40 2.5 22.5 25x25 64 502.65 2.10 127 997.45 4.30 255 2002.77 8.60 3 27 30x30 53 499.51 3.10 106 999.02 6.30 212 1998.05 12.50 4 21 25x25 40 502.65 1.80 80 1005.31 3.65 159 1998.05 7.30 4 26 30x30 40 502.65 3.05 80 1005.31 6.00 159 1998.05 11.90 4 36 40x40 40 502.65 5.50 80 1005.31 11.10 159 1998.05 22.00 5 45 50X50 32 502.65 8.30 64 1005.31 17.50 128 2010.31 34.60 6 54 60x60 27 508.93 12.65 53 999.02 25.00 106 1998.05 51.00 8 72 80X80 20 502.65 21.40 40 1005.31 42.70 80 2010.62 85.40
