| Seals Types | ZZ,Z,2RS,rs,RZ,2RZ,OPEN |
| Vibration Level | Z1V1,Z2V2,Z3V3 |
| Clearance | C2,C0,C3,C4,C5 |
| Tolerance Codes | ABEC-1,ABEC-3,ABEC-5 |
| Materral | GCr15-China/AISI52100-USA/Din100Cr6-Germany |
| MOQ | 1Set at least |
| Delivery Time | 5-10 days after contract |
| Payment Terms | TT/PAPAL/WESTERN UNION |
| Package | Tube package+outer carton+pallets;Single box+outer carton+pallets;
Tube pavkge+middle box+outer carton+pallets;According to your requirement |
bearing deep groove ball bearing bearing manufacturer 6200 6201 6202 6203 6204 6205 ball bearing
Limiting speeds(rpm)Mass(Kg) | | | | d | D | B | rs min | Cr | Cor | Grease | Oil | (Approx.) |
| 62 Series | 6200 | 10 | 30 | 9 | 0.6 | 5.1 | 2.39 | 25,000 | 30,000 | 0.032 |
| | 6201 | 12 | 32 | 10 | 0.6 | 6.1 | 2.75 | 22,000 | 26,000 | 0.037 |
| | 6202 | 15 | 35 | 11 | 0.6 | 7.75 | 3.6 | 19,000 | 23,000 | 0.045 |
| | 6203 | 17 | 40 | 12 | 0.6 | 9.6 | 4.6 | 18,000 | 21,000 | 0.066 |
| | 6204 | 20 | 47 | 14 | 1 | 12.8 | 6.65 | 16,000 | 18,000 | 0.106 |
| | 6205 | 25 | 52 | 15 | 1 | 14 | 7.85 | 13,000 | 15,000 | 0.128 |
| | 6206 | 30 | 62 | 16 | 1 | 19.5 | 11.3 | 11,000 | 13,000 | 0.199 |
| | 6207 | 35 | 72 | 17 | 1.1 | 25.7 | 15.3 | 9,800 | 11,000 | 0.288 |
| | 6208 | 40 | 80 | 18 | 1.1 | 29.1 | 17.8 | 8,700 | 10,000 | 0.366 |
| | 6209 | 45 | 85 | 19 | 1.1 | 32.5 | 20.4 | 7,800 | 9,200 | 0.398 |
| | 6210 | 50 | 90 | 20 | 1.1 | 35 | 23.2 | 7,100 | 8,300 | 0.454 |
| | 6211 | 55 | 100 | 21 | 1.5 | 43.5 | 29.2 | 6,400 | 7,600 | 0.601 |
| | 6212 | 60 | 110 | 22 | 1.5 | 52.5 | 36 | 6,000 | 7,000 | 0.783 |
| | 6213 | 65 | 120 | 23 | 1.5 | 57.5 | 40 | 5,500 | 6,500 | 0.99 |
| | 6214 | 70 | 125 | 24 | 1.5 | 62 | 44 | 5,100 | 6,000 | 1.07 |
| | 6215 | 75 | 130 | 25 | 1.5 | 66 | 49.5 | 4,800 | 5,600 | 1.18 |
| | 6216 | 80 | 140 | 26 | 2 | 72.5 | 53 | 4,500 | 5,300 | 1.4 |
| | 6217 | 85 | 150 | 28 | 2 | 83.5 | 64 | 4,200 | 5,000 | 1.79 |
| | 6218 | 90 | 160 | 30 | 2 | 96 | 71.5 | 4,000 | 4,700 | 2.15 |
| | 6219 | 95 | 170 | 32 | 2.1 | 109 | 82 | 3,700 | 4,400 | 2.62 |
| | 6220 | 100 | 180 | 34 | 2.1 | 122 | 93 | 3,500 | 4,200 | 3.14 |
| | 6221 | 105 | 190 | 36 | 2.1 | 133 | 105 | 3,400 | 4,000 | 3.7 |
| | 6222 | 110 | 200 | 38 | 2.1 | 144 | 117 | 3,200 | 3,800 | 4.36 |
| | 6224 | 120 | 215 | 40 | 2.1 | 155 | 131 | 2,900 | 3,400 | 5.15 |
| | 6226 | 130 | 230 | 40 | 3 | 167 | 146 | 2,700 | 3,100 | 5.82 |
| | 6228 | 140 | 250 | 42 | 3 | 166 | 150 | 2,500 | 2,900 | 7.57 |
| | 6230 | 150 | 270 | 45 | 3 | 176 | 168 | 2,300 | 2,700 | 9.41 |
| | 6232 | 160 | 290 | 48 | 3 | 185 | 186 | 2,100 | 2,500 | 11.7 |
| | 6234 | 170 | 310 | 52 | 4 | 212 | 223 | 2,000 | 2,400 | 14.5 |
| | 6236 | 180 | 320 | 52 | 4 | 227 | 241 | 1,900 | 2,200 | 15.1 |
| | 6238 | 190 | 340 | 55 | 4 | 255 | 281 | 1,800 | 2,100 | 18.2 |
| | 6240 | 200 | 360 | 58 | 4 | 269 | 310 | 1,700 | 2,000 | 21.6 |
| | 6244 | 220 | 400 | 65 | 4 | 297 | 365 | 1,500 | 1,800 | 30.2 |
| | 6248 | 240 | 440 | 72 | 4 | 358 | 465 | 3,000 | 2,600 | 53.9 |
| | 6252M | 260 | 440 | 80 | 5 | 390 | 530 | 2,600 | 2,400 | 68.3 |
| | 62/22 | 22 | 50 | 14 | 1 | 1320 | 690 | 14,000 | 17,000 | 0.117 |
| | 62/28 | 28 | 58 | 16 | 1 | 1830 | 995 | 12,000 | 14,000 | 0.171 |
| | 62/32 | 32 | 65 | 17 | 1 | 2110 | 1190 | 11,000 | 12,000 | 0.226 |
