model

d

D

width

203-KRR-AH05

13

40

18,3

202-KRR

15

35

14,4

203-KRR-AH02

16,2

40

18,3

203-KRR

17

40

18,3

204-KRR

20

47

17,7

205-KRR

25

52

21

206-KRR

30

62

24

207-KRR-AH03

35

72

25

208-KRR-AH04

38,892

80

27,5

208-KRR

40

80

27

209-KRR

45

85

30

210-KRR

50

90

30

211-KRR

55

100

36

212-KRR

60

110

36

Type: Other Type
Bore Size: 16.26 mm
Outside Diameter: 40.00 mm
Model Number: 203KRR2
Precision Rating: P5
Seals Type: 2RS
Outer ring width: 12mm
Inner ring width: 18.288mm
Basic dynamic load rating: 9.6kn
Basic static load rating: 4.6kn
Weight: 0.077kg

Specifications:
1. Used for agricultural machine
2. Have long service life
3. Hex and square bore
4. Large quantity in stock

Packaging & Delivery:
Packaging Detail: 1. Industrial packing 2. Single box packing 3. Export standard packing
Delivery Detail: 1-3 days upon receipt of deposit

Bearing   ref.	d	D	B	Mass(kg)
513071(BCA)	27	60	50	0.56
DAC2858W(DAC28582RK)	28	58	42	0.47
DAC286142AW	28	61	42	0.56
DAC3060372RS	30	60	37	0.42
DAC3060W	30	60.03	37	0.45
DAC3064W2RKBCS28	30	64	42	0.49
DAC3063W-1	30	63.03	42	0.54
DAC3273W	32	73	54	0.98
DAC3464D	34	64	34	0.43
DAC3464G12RS	34	64	37	0.48
DAC3468DW	34	68	37	0.55
DAC34682RS	34	68	42	0.64
DAC3568W-6	34.99	68.02	33	0.46
DAC3577W-3	34.99	77.04	42	0.86
DAC3562AW	35	61.8	31	0.35
DAC3564A-1	35	64	37	0.41
DAC3565WCS30	35	65	35	0.4
DAC3568A2RS	35	68	37	0.52
DAC3568W-6	35	68.02	33	0.47
DAC357234A	35	72	34	0.58
DAC357233B-1W	35	72.02	33	0.56
DAC357245CW2RS	35	72	45	0.63
DAC3580W-3HR4	35	80	45	1.1
DAC3665W	36	65	37	0.45
DAC3668AWCS36	36	68	33	0.48
DAC367234A	36	72.05	34	0.58
DAC3870BW	38	70	38	0.55
DAC3871W-2	38	71.02	33	0.5
DAC3872A	38	72	34	0.59
DAC3872W-3	38	72.02	36	0.54
DAC3872W-10	38	72	40	0.63
DAC3873-1	38	73	40	0.67
DAC3874W-6	38	74.02	36	0.6
DE0892(NTN)	38	74	50	0.78
DAC2880W-1	37.967	80.02	36	0.79
DAC3972AW4	39	72	37	0.56
