Zlyj Series Gearbox for Plastic Extrusion Machinery
Zhejiang Pinbo Plastic Machinery Co., Ltd.- Application：Machinery
- Function：Speed Reduction
- Layout：Three-Ring
- Hardness：Hardened Tooth Surface
- Installation：Torque Arm Type
- Step：Stepless
Base Info
- Type：Bevel Gear
- Brand Name：Pym
- Input Speed：800
- Output Torque：525
- Rated Power：5.5kw
- Lead Time：25days
- Screw Design：Single-Screw
- Color：Red, Blue, White.etc
- Transport Package：Stardand
- Specification：CE BV SGS TUV
- Trademark：PYM
- Origin：Wenzhou, Zhejiang
- HS Code：847790000
- Production Capacity：300pieces Per Month
Description
TypeSpec Input
Power
(kw) N
( enter) N
(output) Output
Torque Permitted axial thrust of output shaft(KN) Screw Diameter Length-diameter ratio (N@m) ZLYJ 112-8 5.5 800 100 525 35 Ø35 25:01:00 133-8 8 800 100 764 39 Ø50 25:01:00 146-10 11 1000 100 1050 54 Ø55 25:01:00 173-10 18.5 900 90 1962 110 Ø65 25:01:00 200-12.5 30 1000 80 3581 155 Ø75 25:01:00 225-12.5 45 1000 80 5371 180 Ø90 25:01:00 250-16 55 1120 70 7503 192 Ø105 25:01:00 280-16 75 960 60 7643 258 Ø110 25:01:00 315-16 85 960 60 13528 287 Ø120 25:01:00 330-16 110 960 60 17507 360 Ø135 25:01:00 375-16 132 960 60 21008 390 Ø150 25:01:00 395-16 185 960 60 29442 400 Ø160 25:01:00 420-16 160 960 60 31831 430 Ø160 25:01:00 420-16 220 960 60 31831 430 Ø170 25:01:00 450-20 213 1000 60 40640 500 Ø160/Ø170 25:01:00 560-17 540 1000 50 84034 700 Ø200 25:01:00 630-10 540 1000 50 103132 770 Ø250 25:01:00
Power
(kw)
( enter)
(output)
Torque
