• Model NO.：K5+(ATB)
• Type：Diamond Saw Blade
• Transport Package：Carton Box
• Specification：355*60*3.2,2.5*36Z+4R
• Trademark：KWS
• Origin：Chengdu(China)
• HS Code：820820000
• Production Capacity：30000,Month

NO.NAMEOD*Bore*Thickness*Teeth  1 Ripping sawblades(K5 Type)160*50*2.5/2.0*24T+3T 5*10 Double keyway2 Ripping sawblades(K5 Type)180*50*2.5/2.0*24T+3T 5*10 Double keyway3 Ripping sawblades(K5 Type)205*50*2.5/2.0*30T+3T 5*10 Double keyway4 Ripping sawblades(K5 Type)230*40*2.5/2.0*30T+3T 5*10 Double keyway5 Ripping sawblades(K5 Type)230*50*2.5/2.0*30T+3T 5*10 Double keyway6 Ripping sawblades(K5 Type)255*50*2.5/2.0*30T+4T 5*10 Double keyway7 Ripping sawblades(K5 Type)305*50*3.0/2.4*36T+4T 5*10 Double keyway8 Ripping sawblades(K5 Type)305*70*3.0/2.4*36T+4T 7*21 Double keyway9 Ripping sawblades(K5 Type)355*60*3.2/2.5*36T+4T 7*14 Double keyway NO.NAMEOD*Bore*Thickness*Teeth  1 Ripping sawblades(K5 Type)150*45*2.2/1.7*24T+3T 4*8 Double keyway2 Ripping sawblades(K5 Type)230*40*2.2/1.7*30T+3T 6*12 Double keyway3 Ripping sawblades(K5 Type)230*45*2.2/1.7*30T+3T 4*8 Double keyway4 Ripping sawblades(K5 Type)405*60*3.4/2.7*36T+6T 6*12 Double keywayMachines: Circular ripping saw, square multi-rip saw etc.
Application: Suitable for cutting soft and hard wood dried at maximum 15% humidity
Technical information: New CP technology with chrome surface treating. Rakers can be made near inner side or outside of the saw body.

Advantages: Anti-rusted surface treating refuses any glue and saw dust. The thin kerf rakers keep preventing the wood contact with saw body. Otherwise increasing much extra friction. High quality saw body provides very stable cutting performance and good heat-resistance.
Tips: Do not enlarges the inner bore and keyway. Clear away the dust from the sawblades

ΔAll size can be customized according to your requirements
