135n. M Peak Torque Right Anlge Planetary Gearbox for Servo Motor

Anhui High Precision Gear Transmission Co., Ltd.
  • Application：Motor, Machinery, Marine, Agricultural Machinery, Laser Cutting Machine
  • Function：Distribution Power, Change Drive Direction, Speed Changing, Speed Reduction
  • Layout：Coaxial
  • Hardness：Hardened Tooth Surface
  • Installation：Vertical Type
  • Step：Double-Step

Base Info

  • Model NO.：ZSPLF60,ZSPLF90
  • Type：Planetary Gear Box
  • Applicable Industries：Manufacturing Plant, Machinery Repair Shops, Print
  • Gearing Arrangement：Planetary
  • Input Flange Diameter：60mm and 90mm Frame
  • Rated Input Speed：3000rpm
  • Output Torque：39- 100 N.M
  • Output Speed：43 Rpm- 750 Rpm
  • Speed Ratio：4,5,7,10. Double Stage:16,20,25,28,35,40,50,70
  • Certification：ISO9001 & CE
  • Housing Material：20crmn
  • Warranty：1 Year
  • Material of Shaft：Standard Material
  • Material of Gear：High Precision Grinding
  • Customized Support：OEM, ODM
  • Transport Package：Carton Box or Wooden Box
  • Trademark：HPS
  • Origin：China
  • HS Code：8483402000
  • Production Capacity：500000PCS,Year

Description

Overview

Product Description




8060901004Application Field

Why Choose Us

 FAQ



Q1:Which areas are your products mainly used in?A:At present, we have two main products: precision planetary gear reducer and solar geared motor. Most of the precision planetary reducers are used in automation fields, such as medical equipment, 3D printers, door openers, tapping machines, CNC lathes and a series of automation equipment. In addition, our solar geared motors are used in photovoltaic power generation projects, which are mainly combined with rotary drives to drive solar panels to track sunlight.
Q2: How to choose the suitable planetary gearbox?
A :First of all, we need you to be able to provide relevant parameters. If you have a motor drawing, it will let us recommend a suitable gearbox for you faster. If not, we hope you can provide the following motor parameters: output speed, output torque, voltage, current, IP, noise, operating conditions, motor size and power, etc.
Q3: What is the price ?
A : The main determining factor for the price of each product is the order volume. You can communicate with us and let us understand each other. I believe that our prices, product quality and our services can definitely make you satisfied.Q4: Do you provide customized service?A: Yes, we provide customized services. You only need to put forward your needs, and we will do our best to provide you with a plan, make plans, and try our best to meet your needs.
