HRC45 Professional 4 Flutes Solid Carbide End Mill Milling Cutter
SHANGHAI EASYDRILL INDUSTRIAL CO., LTD.- Coating：Coating
- Tooth Form：Spiral Tooth
- Tooth Space：Sparse Tooth
- Structure：Indexable Type
- Material：Tungsten Steel
- Type：Face Milling Cutter
Base Info
- Flutes：4 Flutes
- Overlength：50-200mm
- Package：Plastic Box or as Per Request
- Min Qty：10PCS,Size
- Diameter：4.0-20.0mm
- Transport Package：Plastic Box
- Specification：1mm-20mm
- Trademark：EASYDRILL
- Origin：China
- Production Capacity：10000PCS,Month
Description
Tungsten Carbide Flat Endmill, Square End Mill Cutting Tools For Metal(Standard Type)Diameter Flute Length Flute O.AL Shank Dia 1 3 4 50 4 1.5 4.5 4 50 4 2 6 4 50 4 2.5 7.5 4 50 4 3 9 4 50 4 4 12 4 50 4 5 15 4 50 6 6 18 4 50 6 8 24 4 60 8 10 30 4 75 10 12 36 4 75 12
| HRC | APPLICATION |
| 45°end mill for aluminium | Aluminum alloy, Copper alloy, Resin treatment |
| 45°Carbide end mill | Carbide steel, Alloy steel, Tool steel |
| 50°Carbide end mill | Carbide steel, Alloy steel, Tool steel, Hardened & tempered steel |
| 55°Aluminum end mill | Aluminum alloy,Copper alloy, Resin treatment |
| 55°Carbide end mill | Carbide steel, Alloy steel,tool steel,Hardened & tempered steel, HRC ≈52 hardened steel |
| 58°Carbide end mill | Hardened & tempered steel, HRC≈52 to 55 hardened steel |
| 60°Stainless steel end mill | Stainless steel, Ti alloy, |
| 60°Carbide end mill | Hardened & tempered steel, HRC≈52 to 55 hardened steel,HRC58 to 65 hardened steel, stainless steel, Ti alloy |
| 65°Carbide end mill | HRC≈52 to 55 hardened steel,HRC58 to 65 hardened steel |
